GYSFLASH 30.12 PL Battery Charger (UK)
GYSFLASH 30.12 PL Battery Charger (UK)
The GYSFLASH 30.12 PL (UK) is a professional multi-function 30A battery charger designed for workshops and auto electricians. Supporting both 12V Lead-Acid and Lithium Iron Phosphate (LiFePO4) batteries, it combines intelligent charging technology, automatic temperature compensation and advanced cell balancing into a compact, portable unit built for daily professional use.
Key Features
- 30A constant output — 100% duty cycle at 40°C for sustained professional use
- Dual battery chemistry support — Pb mode for 12V Lead-Acid (15–375Ah) and LiFePO4 mode for Lithium (7–375Ah)
- 3 selectable charging currents — 7A, 15A and 30A for flexible application across battery sizes
- Showroom mode — 30A current compensation to power vehicle electrical accessories during demonstrations without draining the battery
- Automatic temperature compensation — high-sensitivity sensor adjusts charging parameters based on ambient temperature
- SOS Recovery — recovers deeply discharged batteries that standard chargers cannot detect
- UVP Wake-up function — reactivates batteries locked in protection mode after deep discharge
- 8-step intelligent charging curve (Lithium) — fully automatic for safe, optimised Lithium charging
- EBS technology — ensures perfect cell balancing across Lithium battery packs
- Full safety protection — short circuit, reverse polarity and overcharge protection as standard
- Compact and portable — lightweight design ideal for workshop bench or on-site use
- Supplied with clamps and connection terminals
Technical Specifications
| Specification | Detail |
|---|---|
| Power Supply | 230V AC |
| Output Current | 7A / 15A / 30A |
| Duty Cycle | 30A at 100% (40°C) |
| Battery Voltage | 12V |
| Battery Types | Lead-Acid (Pb), Lithium Iron Phosphate (LiFePO4) |
| Pb Battery Range | 15–375Ah |
| LiFePO4 Battery Range | 7–375Ah |
| Dimensions | 190 × 190 × 73mm |
| Weight | 1.9kg |
| Supplied With | Clamps and connection terminals |
Charging Modes
- Pb Mode — intelligent multi-step charging for 12V Lead-Acid batteries from 15 to 375Ah
- LiFePO4 Mode — 8-step automatic charging curve with EBS cell balancing for Lithium Iron Phosphate batteries from 7 to 375Ah
- Showroom Mode — 30A current compensation for powering vehicle accessories during demonstrations without battery drain
Frequently Asked Questions
Can the GYSFLASH 30.12 PL charge Lithium batteries?
Yes — it supports Lithium Iron Phosphate (LiFePO4) batteries from 7 to 375Ah using an 8-step automatic charging curve and EBS cell balancing technology.
What is SOS Recovery?
SOS Recovery allows the charger to detect and recover deeply discharged batteries that have fallen below the threshold standard chargers can detect, preventing unnecessary battery replacement.
What is the UVP Wake-up function?
UVP Wake-up reactivates batteries that have entered protection mode following deep discharge, restoring them to a chargeable state.
Is it suitable for showroom or demonstration use?
Yes — Showroom mode delivers 30A current compensation to power vehicle electrical systems during demonstrations without drawing from the battery.
UK-Based Support & Genuine Warranty Protection
When you buy from Dunns Automotive, you're buying from an authorised GYS UK distributor. Every product comes with full UK warranty coverage and support from our UK-based team.
